型號 | 額定電壓比（V) | 額定頻率（hz) | 準確級及相應的額定輸出（vA) | 極限輸出（VA) | 額定絕緣水平（KV) | 備注 | |||
0.2 | 0.5 | 1 | 6P | ||||||
JDZ11-3A | 3000/100 | 50,60 | 40 | 100 | 200 | 100 | 300 | 3.6/25/40 | 同UNZ10 |
JDZ11-6A | 6000/100 | 40 | 100 | 200 | 100 | 300 | 7.2/32/60 | ||
JDZ11-10A | 10000/100 | 40 | 100 | 200 | 100 | 300 | 12/42/75 | ||
JDZ11-3B | 3000/100 | 50 | 120 | 240 | 100 | 500 | 3.6/25/40 | ||
JDZ11-6B | 6000/100 | 50 | 120 | 240 | 100 | 500 | 7.2/32/60 | ||
JDZ11-10B | 10000/100 | 50 | 120 | 240 | 100 | 500 | 12/42/75 | ||
JDZX11-3A | 3000/√3/100/√3/100/3 | 30 | 90 | 180 | 100 | 400 | 3.6/25/40 | 同UNZ10 | |
JDZX11-6A | 6000/√3/100/√3/100/3 | 30 | 90 | 180 | 100 | 400 | 7.2/32/60 | ||
JDZX11-10A | 10000/√3/100/√3/100/3 | 30 | 90 | 180 | 100 | 400 | 12/42/75 | ||
JDZX11-3B | 3000/√3/100/√3/100/3 | 40 | 100 | 200 | 100 | 600 | 3.6/25/40 | ||
JDZX11-6B | 6000/√3/100/√3/100/3 | 40 | 100 | 200 | 100 | 600 | 7.2/32/60 | ||
JDZX11-10B | 10000/√3/100/√3/100/3 | 40 | 100 | 200 | 600 | 12/42/75 | |||
JDZX11-3AG | 3000/√3/100/√3/100/3 | 60 | 400 | 3.6/25/40 | |||||
JDZX11-6AG | 6000/√3/100/√3/100/3 | 60 | 400 | 7.2/32/60 | |||||
JDZX11-10AG | 10000/√3/100/√3/100/3 | 60 | 400 | 12/42/75 | |||||
JDZX11-3BG | 3000/√3/100/√3/100/3 | 60 | 600 | 3.6/25/40 | |||||
JDZX11-6BG | 6000/√3/100/√3/100/3 | 60 | 600 | 7.2/32/60 | |||||
JDZX11-10BG | 10000/√3/100/√3/100/3 | 60 | 600 | 12/42/75 | |||||
